Kombucha Brewing System: Complete Commercial Equipment and Production Guide
| MOQ: | 1 Sets |
| Price: | 10000 USD |
| Delivery Period: | 2 months |
| Payment Method: | L/C,T/T |
| Supply Capacity: | 200 sets / days |
Detail Information
Place of Origin
China
Brand Name
Center Enamel
Certification
ASME,ISO 9001,CE, NSF/ANSI 61, WRAS, ISO 28765, LFGB, BSCI, ISO 45001
Material:
Stainless Steel, Carbon Steel
Size:
Customized
Design Pressure:
0.1-10 Mpa
Applications:
Chemical, Food Processing, Beverage Processing, Brewing, Metallurgy, Oil Refining, Pharmaceuticals
Highlight:
commercial kombucha brewing system
,kombucha production equipment guide
,kombucha storage tank system
Product Description
Kombucha Brewing System: Complete Commercial Equipment and Production Guide
Answering the core question: What is a commercial kombucha brewing system and how is it structured for scale? A commercial kombucha brewing system is an integrated network of specialized food-grade machinery engineered to manage sweet tea preparation, primary fermentation via a symbiotic culture of bacteria and yeast (SCOBY), secondary flavor infusion, and controlled carbonation. Because kombucha produces organic acids (such as acetic, gluconic, and lactic acid) during fermentation, industrial production relies heavily on corrosion-resistant austenitic stainless steel equipment designed for absolute sanitary compliance and high-volume output.
1. Sweet Tea Preparation and Brewing Kettles
The kombucha brewing process begins with preparing and boiling the base nutrient solution:
-
Industrial Brew Kettles: Heavy-duty stainless steel vessels equipped with steam jackets or high-efficiency electric elements to dissolve organic cane sugar and steep black or green tea leaves uniformly.
-
Wort/Tea Coolers: Sanitary plate heat exchangers that rapidly chill the hot brewed tea down to optimal yeast and bacteria-pitching temperatures before it enters fermentation.
2. Primary Fermentation Tanks (SCOBY Management)
Primary fermentation is where the sweet tea is transformed into acidic, probiotic-rich raw kombucha:
-
Stainless Steel Fermentation Vessels: Fabricated from food-grade austenitic stainless steel (such as AISI 304 or 316L) to resist the corrosive nature of organic acids without leaching metallic tastes into the beverage.
-
Sanitary Manways and Access Ports: Designed with top or side manways to allow safe inoculation, aeration, and management of the SCOBY pellicle or liquid starter cultures.
-
Glycol Dimple Cooling Jackets: Wrapped around the tank body to maintain stable ambient temperatures, preventing overheating during active microbial metabolism.
3. Secondary Fermentation, Flavoring, and Blending
After primary fermentation, raw kombucha is transferred into blending and secondary conditioning vessels:
-
Flavor Infusion Tanks: Equipped with internal agitation sweeps to blend fruit juices, purees, herbs, or botanical extracts evenly into the base kombucha.
-
Bright Tanks for Carbonation: Utilized to chill the flavored kombucha and infuse carbon dioxide ($CO_2$) uniformly using micro-porous stainless steel carbonation stones under controlled pressure prior to packaging.
4. Cleaning-in-Place (CIP) and Sanitary Construction
Maintaining biological purity across a commercial kombucha facility requires rigorous sanitation protocols:
-
Electropolished Finishes: Internal tank walls and piping are ground smooth and electropolished to prevent yeast and bacteria build-up.
-
Automated CIP Systems: Integrated spray balls and sanitary piping loops circulate hot caustic and acid wash solutions to sanitize all vessels efficiently between production cycles.
Kombucha Brewing System Parameters Matrix
| Production Stage | Core Equipment Type | Material Composition | Primary Operational Function |
| Tea Preparation | Steam-Jacketed Boil Kettles | AISI 304 Stainless Steel | Dissolving sugar, steeping tea, and boiling base liquid |
| Primary Fermentation | Cylindrical Fermentation Tanks | AISI 304/316L Stainless Steel | Managing SCOBY fermentation and acid production |
| Flavor Blending | Agitated Blending Tanks | AISI 304 Stainless Steel | Uniformly mixing fruit purees, juices, and extracts |
| Carbonation & Storage | Bright Tanks with Carbonation Stones | AISI 304/316L Stainless Steel | Chilling, carbonating, and holding finished kombucha |
Frequently Asked Questions (FAQ)
Q: What equipment is included in a commercial kombucha brewing system?
A: A complete commercial system includes tea brewing kettles, liquid chillers, stainless steel primary fermentation tanks, flavor-blending vessels, bright tanks with carbonation stones, and an automated CIP cleaning system.
Q: Why is stainless steel used for commercial kombucha tanks instead of reactive metals?
A: Kombucha is acidic due to the production of organic acids like acetic acid. Food-grade austenitic stainless steel (such as AISI 304 or 316L) resists chemical corrosion, prevents metallic off-flavors, and ensures strict hygiene.
Q: How is carbonation achieved in commercial kombucha production?
A: Commercial producers typically use pressurized bright tanks equipped with micro-porous stainless steel carbonation stones to force-carbonate the beverage uniformly before canning or bottling.
Q: What is the role of temperature control in kombucha fermentation tanks?
A: Precise temperature control—managed via glycol cooling jackets—ensures that the symbiotic culture of bacteria and yeast (SCOBY) ferments at a consistent rate, safeguarding flavor profile balance and probiotic viability.
