What is an API 650 Tank?

An API 650 Tank is an aboveground, vertical, cylindrical steel storage tank engineered and constructed in accordance with Standard 650 of the American Petroleum Institute.

These tanks are the global industry standard for safely storing large volumes of liquid hydrocarbons (like crude oil, diesel, and gasoline), chemicals, and water. By definition, API 650 tanks are designed to operate near atmospheric pressure. The standard dictates stringent requirements for material selection, shell design, welding procedures, and non-destructive examination (NDE) to prevent catastrophic leaks, environmental disasters, or structural collapse.

1. Structural Anatomy of an API 650 Tank

To safely contain millions of gallons of hazardous liquids, an API 650 tank consists of several highly regulated components:

• The Shell: The cylindrical outer wall made of stacked "courses" (rings) of steel plates. Because hydrostatic pressure increases with depth, the bottom courses are significantly thicker than the top courses.

• The Bottom (Annular Plate): The flat steel floor of the tank resting on the foundation. The outer perimeter is often reinforced with a thicker ring of steel called an annular plate, which absorbs the bending stresses where the shell meets the floor.

• The Roof: Depending on the stored product's volatility, tanks will either have a Fixed Roof (cone or dome shaped) or a Floating Roof (an internal or external pontoon roof that floats directly on the liquid surface to eliminate vapor emissions).

• Wind Girders: Heavy structural steel rings welded to the upper courses of the shell to prevent the empty tank from buckling inward during high wind events.

2. Engineering the Shell: The "One-Foot Method"

The most critical engineering calculation in API 650 is determining how thick the steel shell must be to hold back the immense outward push of the liquid (hydrostatic head).

For tanks under 61 meters (200 feet) in diameter, engineers utilize the One-Foot Method. This method calculates the required thickness at a point exactly 0.3 meters (one foot) above the bottom of each shell course, as the bottom plate itself provides a slight stiffening effect at the weld joint.

The fundamental design equation is:

Interactive Shell Thickness Calculator (One-Foot Method)

To see how tank dimensions and liquid properties dictate material requirements, use the API 650 engineering simulator below. Adjust the tank size and material parameters to calculate the exact required thickness of the lowest shell course

(Note: API 650 also dictates strict minimum thickness rules based on tank diameter—e.g., tanks over 36 meters must have a minimum nominal thickness of 8 mm, regardless of what the hydrostatic calculation says.)

3. Standard Comparison: API 650 vs. API 620 vs. ASME Sec VIII

A common point of confusion in industrial procurement is deciding which code applies to a specific tank. The deciding factor is almost always internal pressure.

Frequently Asked Questions (FAQ)

Q: Can API 650 tanks be built from stainless steel?

A: Yes. While the vast majority of API 650 tanks are fabricated from carbon steel (like A36 or A283 Grade C), Appendix S of the standard explicitly covers the design and construction of austenitic stainless steel tanks for corrosive chemicals or food-grade storage.

Q: What is a "Frangible Roof" in API 650?

A: A frangible roof is a specialized safety design. The weld connecting the roof to the shell is deliberately engineered to be weaker than the welds connecting the shell to the bottom plate. In the event of a massive explosion or overpressure event inside the tank, the roof will tear off, venting the pressure upward and saving the side walls and bottom from rupturing, which prevents a catastrophic liquid spill.

Q: How do you inspect an API 650 tank over its lifetime?

A: Once an API 650 tank is commissioned, its lifetime maintenance and inspection fall under a different code: API 653. This standard dictates how often the tank must be drained, ultrasonically tested for wall thinning, and structurally evaluated for continued safe operation.
